Ventura AERO 20FP25H1CT-R Aircraft Batteries

Ventura AERO 20FP25H1CT-R Aircraft Batteries

Brand:VENTURA

Availability:In Stock

Product Code:20FP25H1C-R

Batterie 20 FP 25 H1C-R have bat-tery container,battery lid and power plug origin in CIS states.

WhatsApp：+86 186 3096 8614

WANG ZE LONG

The cell is the basic component of the nickel-cadmium battery(fig.2).The"Ventura AERO"C"is a further developed cell,ensuring even more safety and reliability in flying operations.Optically"Safety Plus Power"cells are indicated by the yel-low and green color of the cell-lid.Cell comprises positive and negative electrodes in sinter-plate design,consisting of separators,electrolyte,cell con-tainer and a vent.

Accumulator components:

1-negative electrode

2-positive electrode

3-separator

4-plate pack

5-negative pole bolt

6-positive pole bolt

7-electrolyte level indicator

8-baffle

9-pole bolt sealing ring

10-cell cover

11-vent sealing ring

12-vent

13-upper pole nut

14-spring washer

15-lower pole nut

16-limiting cap

17-pole bolt sealing ring

18-cell container

Characteristics Aggregates and Avionics

Ambient temperature-40...+71°С

Characteristics of Aggregates

Rated power 24W

Voltage Current The current permissible starting load-1550(A)Current permissible continuous load-500(A)

Properties

Weight 24Kg

Purpose

Aircraft On most cargo aircraft.

Helicopter MI-17
